FACTORS AFFECTING CONCRETE STRENGTH AND WORKABILITY

The strength and workability of concrete are both critical factors that need to be considered in the making of concrete. The strength of concrete determines its ability to withstand various loads, while workability refers to the ease with which it can be placed, compacted, and finished. Both factors are essential for producing a high-quality, durable concrete structure. A balance between these two factors needs to be achieved during the concrete mixing process to ensure that the final product meets the desired strength and workability requirements.

Factors Affecting Concrete's Strength

The strength of concrete can be affected by various factors, including:

Water Cement Ratio

The water-to-cement ratio is a critical factor that affects both the strength and workability of concrete. A higher water-to-cement ratio generally results in higher workability but lower strength.

Cement aggregate ratio

The cement aggregate ratio in concrete refers to the proportion of cement to aggregate (usually sand and gravel or crushed stone) used in the concrete mix. This ratio is typically expressed in terms of the volume or weight of cement to the volume or weight of aggregate.

The ideal cement aggregate ratio in concrete depends on several factors, such as the strength requirements, workability, and durability of the concrete. A higher cement aggregate ratio will result in a higher strength concrete, but it may also reduce the workability of the mix, making it more challenging to place and finish. On the other hand, a lower cement aggregate ratio will result in a more workable mix, but the concrete’s strength may be lower.

Grade of aggregate

The grade of aggregate refers to the particle size distribution of the aggregate material. In other words, it refers to the range of particle sizes present in the aggregate. The grading of aggregate can affect the workability, strength, and durability of concrete.

Aggregates are typically graded by size, with larger particles being used for the coarse aggregate and smaller particles used for the fine aggregate. The grading of the aggregate is determined by performing a sieve analysis, where the aggregate is passed through a series of sieves of different sizes to separate the particles by size.

In general, a well-graded aggregate has a range of particle sizes that fill the voids between larger particles, resulting in a more compact and workable mix. A poorly-graded aggregate, on the other hand, can result in a mix that is more difficult to work with and may have a lower strength.

Shape and size of aggregate

Rounded aggregates have more strength than flaky aggregates because they have more surface area. Furthermore, the larger the size of the aggregate, the greater the surface area; therefore, the bonds are weak and finally result in poor strength. As a result, smaller aggregates are preferable because the load distribution will be altered.

Compaction

Compaction is an essential step in the process of making concrete, as it helps to remove air voids and ensure that the concrete is dense and well-bonded. Proper compaction of concrete can significantly affect its strength and durability.

Compaction affects the strength of concrete in two main ways:

  • Increased density: Compaction helps to increase the density of the concrete by removing air voids and filling in the spaces between the particles of aggregate. This, in turn, helps to increase the strength of the concrete by improving its load-carrying capacity and reducing the risk of cracking or failure under stress.
  • Improved bonding: Compaction helps to improve the bonding between the cement paste and the aggregate particles. This, in turn, helps to improve the strength and durability of the concrete by reducing the risk of delamination or separation between the cement paste and the aggregate.

Proper compaction of concrete requires careful attention to several factors, such as the water-cement ratio, aggregate shape and size, placement temperature, and the use of appropriate compaction equipment and techniques. Over compaction can lead to a loss of workability and result in a weaker concrete mix, while under compaction can lead to a less dense concrete mix with air voids and reduced strength.

Curing

It should be completed within 7 to 14 days. Curing helps concrete interlock better and maintain moisture and temperature. Concrete’s strength increases with curing time. There are numerous ways to cure, including membrane curing, spray curing, steam curing, and so forth.

Cement and water content

The cement and water content should be chosen so that the ratio is ideal for strength, according to the IS code. A loss of strength will follow any disparity between the two. In order to increase the strength of building elements for improved loading circumstances that would prevent the structure from collapsing, mix design methods have been developed.

Factors Affecting Workability

Workability is an important property of concrete that affects its ease of mixing, placing, and finishing. The following factors can affect the workability of concrete:

Water content and the water-to-cement ratio

The greater the water content, the greater the workability of the concrete. Abram’s law states that the water-cement ratio has a direct relationship with the strength of usable concrete.The ratio of the solid volume to the void volume is known as the water-cement ratio. As the spaces are smaller, it gets stronger. A stronger concrete will result from a lower water-to-cement ratio and a lower void volume-to-solid volume ratio.

Mix proportion and aggregate cement ratio

Concrete becomes more linear as the aggregate-cement ratio rises because less cement is needed for moisturizing, which limits the movement of the aggregate. More paste is used to make the mixture cohesive and more workable in the case of rich concrete with a lower aggregate-to-cement ratio.

Size of aggregate

As discussed in the section on the strength of concrete, the larger the aggregate size, the smaller the surface area, and hence the less water required for moisturization. Less paste will be used as a result, which will save money, and this will increase the workability.

Shape of the aggregate

Angular or flaky aggregates make the mix rough and harder to mix or blend when compared to round or cubical aggregates. Rounded aggregates are more workable because they contain a reduced surface area and voids, which reduce friction. Since river sand and gravel are more workable than crushed ones, they are used more frequently.

Surface texture

Aggregate with a smooth texture is easier to deal with than one with a rough texture since it has less friction and a smaller surface area for mixing.

Grading

The better the grading, the better the workability because it has the fewest voids. Well-graded aggregates are chosen for greater workability because this aspect has the greatest impact on the workability of concrete.

Mixing and Handling Techniques

Proper mixing techniques and equipment, such as appropriate mixing duration and uniform distribution of materials, influence workability. Handling and transportation methods can also impact workability.
